Specs
UT6573 Key Specifications
UT6573
Horsepower
73.1 hp
Lift Capacity at 24" behind Lift Point
3,898 lb
PTO HP
56.3 hp
Transmission Type
3 Range Powershuttle (w/electronic clutch)
Width
83.5 in
Turning Radius
12' 10"
Wheelbase
6' 11"
Engine
UT6573
Emissions Tier (EPA)
Tier 4
Horsepower
73.1 hp
Displacement
149 in³
Number of Cylinders
4
Engine Model
4HT-TP4A
Performance
UT6573
Operating Weight
5,960 lb
Travel Speed
19.9 mph
Travel Speed - Reverse
19.6 mph
3-Point Hitch
Category 2
3-pt Lift Control Type
Position with Draft Control
Lift Capacity at 24" behind Lift Point
3,898 lb
Rear PTO System
Independent
Rear PTO - RPM
540
PTO HP
56.3 hp
Capacities
UT6573
Fuel Tank
25.1 gal
Hydraulic System
UT6573
Implement Hydraulic Flow
10.99 gal/min
Total Hydraulic Flow
19.23 gal/min
Steering Hydraulic Flow
8.24 gal/min
Drive System
UT6573
Brake Type
Wet Multi Disc
Transmission Type
3 Range Powershuttle (w/electronic clutch)
Dimension
UT6573
Length
150 in
Width
83.5 in
Height
101.1 in
Ground Clearance
12.3 in
Turning Radius
12' 10"
Wheelbase
6' 11"
Front Tire Size
Front Industrial (AG, multi-use) 12.5/80-18 (11.2-24, 340/80R18)
Rear Tire Size
Rear Industrial (AG, multi-use) 18.4-24 (16.9-30, 480/80R26)
Loader Attachment
UT6573
Loader Lift Height
10' 9"
Lift Capacity at Bucket Pivot
3,212 lb
Bucket Width
6' 9"
