Specs
ZT5000 Key Specifications
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Engine Model
Kawasaki FX730V Gas Engine
Kawasaki FX730V Gas Engine
Displacement
726 cubic cm
726 cubic cm
Transmission Type
Hydro Gear ZT-3800 Hydrostatic
Hydro Gear ZT-3800 Hydrostatic
Pump Displacement
12 cubic cm
12 cubic cm
Cutting Height Range
1.5-4.8 in / 38-121 mm
1.5-4.8 in / 38-121 mm
Mower Deck
AirFX Dual 10-gauge layer top with 3-gauge and 7-gauge brackets throughout
AirFX Dual 10-gauge layer top with 3-gauge and 7-gauge brackets throughout
Width
52 in
52 in
BobQuote
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Engine
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Engine Model
Kawasaki FX730V Gas Engine
Kawasaki FX730V Gas Engine
Fuel Tank
7.8 gal
7.8 gal
Horsepower
23.5 hp
23.5 hp
Displacement
726 cubic cm
726 cubic cm
Performance
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Machine Weight - Wet
995 lbs
995 lbs
Price
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Power/Electrical
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Additional Product Information
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Transmission
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Transmission Type
Hydro Gear ZT-3800 Hydrostatic
Hydro Gear ZT-3800 Hydrostatic
Pump Displacement
12 cubic cm
12 cubic cm
Oil Capacity
4 qt
4 qt
Mower Seat
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Wheels
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Front Caster Wheel Size
13 x 6.5-6
13 x 6.5-6
Caster Arm
Welded to Frame
Welded to Frame
Drive Wheel Size
24 x 10.5-12
24 x 10.5-12
Frame
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Front and Rear
Welded 7-gauge Steel; 1.5- x 2.5-inch Steel Tubing
Welded 7-gauge Steel; 1.5- x 2.5-inch Steel Tubing
Length
79.8 in
79.8 in
Deck
ZT5000 - 52” Deck
ZT5000 - 61” Deck
Cutting Height Range
1.5-4.8 in / 38-121 mm
1.5-4.8 in / 38-121 mm
Mower Deck
AirFX Dual 10-gauge layer top with 3-gauge and 7-gauge brackets throughout
AirFX Dual 10-gauge layer top with 3-gauge and 7-gauge brackets throughout
Discharge Chute
Flexible Molded Polymer
Flexible Molded Polymer
Mower Blade Tip Speed
18142 ft/min
18142 ft/min
Width
52 in
52 in
