Specs
ZT6000 Key Specifications
ZT6000 - 52” Deck
ZT6000 - 61” Deck
Mower Deck
AirFX™ Cutting System
AirFX™ Cutting System
Width
52 in
61 in
Cutting Height
1-5.5 in.
1-5.5
Engine Model
Kaw FX801V
Kaw FX801V
Displacement
852 cm³
852 cm³
Transmission type
HG ZT-4400 Hydrostatic Transaxles
HG ZT-4400 Hydrostatic Transaxles
Pump Displacement
12 cm³
12 cm³
Deck
ZT6000 - 52” Deck
ZT6000 - 61” Deck
Mower Deck
AirFX™ Cutting System
AirFX™ Cutting System
Width
52 in
61 in
Cutting Height
1-5.5 in.
1-5.5
Blade Tip Speed
18,586 ft/min
18,500 ft/min
Discharge Chute
Flexible Molded Polymer
Flexible Molded Polymer
Engine
ZT6000 - 52” Deck
ZT6000 - 61” Deck
Engine Model
Kaw FX801V
Kaw FX801V
Displacement
852 cm³
852 cm³
Fuel Capacity
15 gal
15 gal
Horsepower
25.5 hp
25.5 hp
Performance
ZT6000 - 52” Deck
ZT6000 - 61” Deck
Weight
1371 lb
1421 lb
Transmission
ZT6000 - 52” Deck
ZT6000 - 61” Deck
Transmission type
HG ZT-4400 Hydrostatic Transaxles
HG ZT-4400 Hydrostatic Transaxles
Pump Displacement
12 cm³
12 cm³
Oil Capacity
4.5 qt_liq_us
4.5 qt_liq_us
Forward Speed
12 mph
12 mph
Reverse Speed
4 mph
4 mph
Electrical
ZT6000 - 52” Deck
ZT6000 - 61” Deck
Charging System
15 A
15 A
Clutch
225 ft·lbf
225 ft·lbf
Frame
ZT6000 - 52” Deck
ZT6000 - 61” Deck
Front/Rear
Welded 0.25 in, 7-gauge Steel; 1.5 x 2.5 in Steel Tubing
Welded 0.25 in, 7-gauge Steel; 1.5 x 2.5 in Steel Tubing
Length
83 in
83 in
Wheels
ZT6000 - 52” Deck
ZT6000 - 61” Deck
Drive Wheel
24 x 10.5-12
24 x 10.5-12
Front Caster Wheel Size
13 x 6.5-6
13 x 6.5-6
Caster Arm Attachment
Bolt On
Bolt-On
Seat
ZT6000 - 52” Deck
ZT6000 - 61” Deck
Seat
High-Back, Full-Mechanical Suspension Seat
High-Back, Full-Mechanical Suspension Seat
Fore-Aft Adjust
Seat Slide Lever
Seat Slide Lever
