Specs
CT1025 Key Specifications
CT1025 HSTD
Horsepower
24.5 hp
Lift Capacity at 24" behind Lift Point
700 lb
PTO HP
18.8 hp
Transmission Type
Infinite, 2 Range Hydrostatic
Width
45.7 in
Turning Radius
8' 3"
Wheelbase
4' 7"
Engine
CT1025 HSTD
Emissions Tier (EPA)
Tier 4
Horsepower
24.5 hp
Displacement
61 in³
Number of Cylinders
3
Gross HP
24.5 hp
Engine Model
3C100LFH-U1
Performance
CT1025 HSTD
Operating Weight
1,521 lb
Travel Speed
11 mph
Travel Speed - Reverse
7.5 mph
3-Point Hitch
Category 1
3-pt Lift Control Type
Hydraulic Position Control System
Lift Capacity at 24" behind Lift Point
700 lb
Rear PTO System
Independent
Rear PTO - RPM
540
PTO HP
18.8 hp
Mid PTO - RPM
2200
Capacities
CT1025 HSTD
Fuel Tank
6.7 gal
Hydraulic System
CT1025 HSTD
Implement Hydraulic Flow
4.6 gal/min
Total Hydraulic Flow
6.4 gal/min
Steering Hydraulic Flow
1.8 gal/min
Drive System
CT1025 HSTD
Brake Type
Wet Multi Disc
Transmission Type
Infinite, 2 Range Hydrostatic
Dimension
CT1025 HSTD
Length
99.3 in
Width
45.7 in
Height
87.6 in
Ground Clearance
6.3 in
Turning Radius
8' 3"
Wheelbase
4' 7"
Front Tire Size
Front Industrial (AG, Turf) 18X8.5-10 (18X8.5-10,18X8.5-10 )
Rear Tire Size
Rear Industrial (AG, Turf) 26X12-12 (26X12-12,26X12-12 )
Loader Attachment
CT1025 HSTD
Loader Lift Height
6' 0"
Lift Capacity at Bucket Pivot
608 lb
Bucket Width
4' 0"
