Specs
L28 Key Specifications
L28 <!-->
Horsepower
24.8 hp
Rated Operating Capacity Straight (ISO)
1,534 lb
Rated Operating Capacity Art. (ISO)
1,222 lb
Operating Weight
4195 lb
Auxiliary Std Flow
12.1 gal/min
Width (over tires)
46.5 in
Engine
<!--> L28 -->
Emissions Tier (EPA)
Tier 4 <!-->
Engine Cooling
Liquid -->
Engine Fuel
Diesel <!-->
Horsepower
24.8 hp
Turbocharged Engine
no -->
Performance
<!--> L28 -->
Rated Operating Capacity Straight (ISO)
1,534 lb
Rated Operating Capacity Art. (ISO)
1,222 lb
ROC with Counterweight Option Straight
1952 lb
ROC with Counterweight Option Art.
1475 lb
Tipping Load Straight
3068 lb
Tipping Load Art.
2444 lb
Operating Weight
4195 lb
Travel Speed
8.3 mph
Capacities
<!--> L28 -->
Fuel Tank
9.6 gal
Hydraulic System
<!--> L28 -->
System Relief @ Quick Couplers
2,900 psi
Auxiliary Std Flow
12.1 gal/min
Drive System
<!--> L28 -->
Drive Type
Hydrostatic drive with 4 individual drive motors <!-->
Dimension
--> L28 <!-->
Length
122.4 in
Length without Attachment
93.2 in
Length with Standard Bucket
122.4 in
Width (over tires)
46.5 in
Width (with bucket)
50 in
Height with Operator Cab
78.1 in
Height to Bucket Hinge Pin Ext
104.3 in
Height to Bucket Hinge Pin Ret
85.4 in
Max Reach
30.9 in
Turning Radius Inside
78.2 in
Turning Radius Outside
100.9 in
Wheelbase
47.2 in
Articulation Angle
43° -->
Dump Angle @ Maximum Height
40° <!-->
Ground Clearance
5.5 in
Rollback Angle
32° -->
Tire Size
23X10.5-12, 8 PLY <!-->
Wheel Tread
36.4 in
Features
--> L28 <!-->
Air Conditioning
Not Applicable -->
Adjustable Seat
Standard <!-->
Backup Alarm
Standard -->
BICS System (Interlock)
Standard <!-->
Cab Enclosure
Optional -->
Cab Heater
Optional <!-->
Operating Lights
Optional -->
Rear Window
Optional <!-->
Lift-Arm Support
Standard -->
Two Speed Travel
Not Applicable <!-->
Deluxe Instrumentation
Not Applicable -->
Hydraulic Bucket Positioning
Standard <!-->
Auxiliary Hydraulics
Standard -->
Spark Arrestor Muffler
Standard <!-->
Bob-Tach Attachment System
Standard -->
Horn
Standard <!-->
Front and Rear Work Lights
Standard -->
Rotating Flashing Beacon
Optional <!-->
Turn Signals
Optional -->
Tires-Ply Rating
8 <!-->
Heavy-Duty Float Tires
Optional -->
Cup Holder
Standard <!-->
Grab Handles
N/A -->
