Specs
Cutting Deck
Anti-scalp wheels
3
Blade engagement
Electric clutch
Blade type
High-Lift blade
Blades
3 pcs
Cutting deck type
11-gauge fabricated
Deck lifting system
Manual, hand operated
Cutting height, max (approximate)
4.5 in
Cutting height, min (approximate)
1.5 in
Cutting height steps
12
Cutting methods
Collect/Mulch/Side discharge
Cutting width
61 in
Deck Wash Port
Yes
Powder-coated cutting deck
Yes
Spindle/mandrel type
Cast Aluminum
Dimensions
Base machine, height
42 in
Base machine, length
75.5 in
Base machine, width
76 in
Tire size, front Diameter
13 in
Tire size, rear Diameter
22 in
Turning radius, min
0 in
Weight
753 lbs
Drive System
Drive method
Lever-operated
Transmission manufacturer
Hydro-Gear
Transmission type
Hydrostatic
Transmission model
ZT 3100
Fan-cooled pumps
Yes
Speed forward max
8.5 mph
Speed reverse max
4.5 mph
Engine
Air filter type
Auto-type Paper
Cylinder displacement
810 cm³
Engine lubrication type
Pressure with Oilfilter
Motor/engine manufacturer
Briggs & Stratton
Engine name
Professional Series
Fuel tank volume (with reserve)
5 gal (US)
Horsepower
26 hp
Equipment
Cup holder
Yes
Headlights
No
Hour meter type
Digital
Seat material
Vinyl
Seat type
18" spring suspended
ROPS
Optional
Warranty
Homeowner Warranty
2 Year Consumer Warranty
