Specs
E60 (Long-Arm)
E60 (Extendable Arm) <!-->
E60 -->
E60 Key Specifications
Operating Weight
12,315 lb
12,646 lb
12,315 lb
Bucket Digging Force
10,261 lbf
10,261 lbf
10,261 lbf
Maximum Reach at Ground Level
246 in
265.2 in
246 in
Width
77.2 in
77.2 in
77.2 in
Tail Swing Type
Conventional <!-->
Conventional -->
Conventional <!-->
<!-->
-->Engine
Emissions Tier (EPA)
Tier 4 -->
Tier 4 <!-->
Tier 4 -->
Engine Fuel
Diesel <!-->
Diesel -->
Diesel <!-->
Maximum Governed RPM
2,200 rpm
2,200 rpm
2,200 rpm
Turbocharged Engine
yes -->
yes <!-->
yes -->
Optional Turbocharged Engine
N/A <!-->
N/A -->
N/A <!-->
Performance
Operating Weight
12,315 lb
12,646 lb
12,315 lb
Weight Class
6 t -->
6 t <!-->
6 t -->
Travel Speed - High
2.8 mph
2.8 mph
2.8 mph
Travel Speed - Low
1.8 mph
1.8 mph
1.8 mph
Arm Digging Force
6,446 lbf
7,104 lbf
6,446 lbf
Bucket Digging Force
10,261 lbf
10,261 lbf
10,261 lbf
Rated Lift Capacity
6411 lb
6345 lb
6411 lb
Lift Radius
118 in
118 in
118 in
Boom Swing - Left
75° <!-->
75° -->
75° <!-->
Boom Swing - Right
50° -->
50° <!-->
50° -->
Maximum Dig Depth
157.2 in
177.6 in
157.2 in
Max Dump Height
171.6 in
182.4 in
171.6 in
Maximum Reach at Ground Level
246 in
265.2 in
246 in
Capacities
Fuel Tank
19 gal
19 gal
19 gal
Hydraulic System
Auxiliary Std Flow
20 gal/min
20 gal/min
20 gal/min
Auxiliary Pressure
3,045 psi
3,045 psi
3,045 psi
Dimension
Length
218.3 in
218.3 in
218.3 in
Overall Length in Travel Position
218.3 in
218.3 in
218.3 in
Width
77.2 in
77.2 in
77.2 in
Height
100.1 in
100.1 in
100.1 in
Height with Operator Cab
100.1 in
100.1 in
100.1 in
Features
Air Conditioning
Optional <!-->
Optional -->
Optional <!-->
Cab Enclosure
Optional -->
Optional <!-->
Optional -->
Cab Heater
Not Applicable <!-->
Not Applicable -->
Not Applicable <!-->
Heater Air Conditioning
Optional -->
Optional <!-->
Optional -->
Radio
Optional <!-->
Optional -->
Optional <!-->
Tail Swing Type
Conventional -->
Conventional <!-->
Conventional -->
Engine Shutdown
Standard <!-->
Standard -->
Standard <!-->
Auxiliary Hydraulics
Standard -->
Standard <!-->
Standard -->
Secondary Auxiliary Hydraulics
Optional <!-->
Optional -->
Optional <!-->
Quick Tach System
Standard -->
Standard <!-->
Standard -->
Rubber Track
Standard <!-->
Standard -->
Standard <!-->
Selectable Auxiliary Hydraulic Flow
Standard -->
Standard <!-->
Standard -->
Angle Blade
Optional <!-->
Optional -->
Optional <!-->
