Specs
E55 Key Specifications
E55
Operating Weight
11357 lbs
Bucket Digging Force
9511 lbf
Maximum Reach at Ground Level
19.4 ft
Width
77.2 in
Engine
E55
Maximum Governed RPM
2200 rpm
Horsepower
49.7 hp
Turbocharged Engine
yes
Performance
E55
Operating Weight
11357 lbs
Weight Class
5 t
Travel Speed - High
2.8 mph
Travel Speed - Low
1.8 mph
Arm Digging Force
6987 lbf
Bucket Digging Force
9511 lbf
Rated Lift Capacity
6746 lbs
Lift Radius
118 in
Boom Swing - Left
75 deg
Boom Swing - Right
50 deg
Maximum Dig Depth
11.4 ft
Max Dump Height
13 ft
Maximum Reach at Ground Level
19.4 ft
Capacities
E55
Fuel Tank
19 gal
Hydraulic System
E55
Auxiliary Std Flow
20 gpm
Auxiliary Pressure
3045 psi
Dimension
E55
Length
208.7 in
Overall Length in Travel Position
208.7 in
Width
77.2 in
Height
100.2 in
Height with Operator Cab
100.2 in
Controls
E55
Price
E55
Additional Product Information
E55
Features
E55
Air Conditioning
Optional
Swing Boom
Standard
Cab Enclosure
Optional
Radio
Optional
Engine Shutdown
Standard
Auxiliary Hydraulics
Standard
Quick Tach System
Standard
Rubber Track
Standard
Selectable Auxiliary Hydraulic Flow
Standard
Angle Blade
Optional
