Specs
E20 Key Specifications
Operating Weight
4,306 lb
Bucket Digging Force
4,684 lbf
Maximum Reach at Ground Level
167.9 in
Width
53.5 in
Tail Swing Type
Zero <!-->
<!-->
<!-->Engine
Emissions Tier (EPA)
Tier 4 -->
Engine Fuel
Diesel <!-->
Maximum Governed RPM
2,500 rpm
Turbocharged Engine
no -->
Optional Turbocharged Engine
N/A <!-->
Performance
Operating Weight
4,306 lb
Weight Class
2 t -->
Travel Speed - High
2.6 mph
Travel Speed - Low
1.3 mph
Arm Digging Force
2,086 lbf
Bucket Digging Force
4,684 lbf
Rated Lift Capacity
1098 lb
Lift Radius
118 in
Boom Swing - Left
80° <!-->
Boom Swing - Right
60° -->
Maximum Dig Depth
101 in
Max Dump Height
106 in
Maximum Reach at Ground Level
167.9 in
Capacities
Fuel Tank
5 gal <!-->
Hydraulic System
Auxiliary Std Flow
7.9 gal/min
Auxiliary Pressure
2,610 psi
Dimension
Length
145.2 in
Overall Length in Travel Position
145.2 in
Width
53.5 in
Height
90.4 in
Height with Operator Cab
90.4 in
Features
Air Conditioning
Not Applicable -->
Cab Enclosure
Optional <!-->
Cab Heater
Optional -->
Heater Air Conditioning
Not Applicable <!-->
Radio
Optional -->
Tail Swing Type
Zero <!-->
Engine Shutdown
Standard -->
Auxiliary Hydraulics
Standard <!-->
Secondary Auxiliary Hydraulics
Not Applicable -->
Quick Tach System
Not Applicable <!-->
Rubber Track
Standard -->
Selectable Auxiliary Hydraulic Flow
Optional <!-->
Angle Blade
Not Applicable -->
