Specs
E48 Key Specifications
Operating Weight
9,830 lb
Bucket Digging Force
9,601 lbf
Maximum Reach at Ground Level
207.1 in
Width
72.8 in
Tail Swing Type
Conventional <!-->
<!-->
-->Engine
Emissions Tier (EPA)
Tier 4 -->
Engine Fuel
Diesel <!-->
Maximum Governed RPM
2,200 rpm
Turbocharged Engine
yes -->
Optional Turbocharged Engine
N/A <!-->
Performance
Operating Weight
9,830 lb
Weight Class
4.5 t
Travel Speed - High
3.3 mph
Travel Speed - Low
1.6 mph
Arm Digging Force
5,820 lbf
Bucket Digging Force
9,601 lbf
Rated Lift Capacity
4921 lb
Lift Radius
118 in
Boom Swing - Left
75° -->
Boom Swing - Right
50° <!-->
Maximum Dig Depth
124.5 in
Max Dump Height
150.6 in
Maximum Reach at Ground Level
207.1 in
Capacities
Fuel Tank
19 gal
Hydraulic System
Auxiliary Std Flow
20 gal/min
Auxiliary Pressure
3,045 psi
Dimension
Length
200.5 in
Overall Length in Travel Position
200.5 in
Width
72.8 in
Height
99.1 in
Height with Operator Cab
99.1 in
Features
Air Conditioning
Optional -->
Cab Enclosure
Optional <!-->
Radio
Optional -->
Tail Swing Type
Conventional <!-->
Engine Shutdown
Standard -->
Auxiliary Hydraulics
Standard <!-->
Quick Tach System
Standard -->
Rubber Track
Standard <!-->
Selectable Auxiliary Hydraulic Flow
Standard -->
Angle Blade
Optional <!-->
