Specs
E32 Key Specifications
E32
E32 (Long-Arm)
E32 (Extendable Arm)
Operating Weight
7,403 lb
8,269 lb
8,497 lb
Bucket Digging Force
7,284 lbf
7,284 lbf
7,284 lbf
Maximum Reach at Ground Level
194.5 in
205.9 in
225.3 in
Width
61.8 in
61.8 in
61.8 in
Tail Swing Type
Conventional
Conventional
Conventional
Engine
E32
E32 (Long-Arm)
E32 (Extendable Arm)
Emissions Tier (EPA)
Tier 4
Tier 4
Tier 4
Engine Fuel
Diesel
Diesel
Diesel
Maximum Governed RPM
2,450 rpm
2,450 rpm
2,450 rpm
Turbocharged Engine
no
no
no
Optional Turbocharged Engine
N/A
N/A
N/A
Performance
E32
E32 (Long-Arm)
E32 (Extendable Arm)
Operating Weight
7,403 lb
8,269 lb
8,497 lb
Weight Class
3.4 t
3.8 t
3.9 t
Travel Speed - High
2.9 mph
2.9 mph
2.9 mph
Travel Speed - Low
1.6 mph
1.6 mph
1.6 mph
Arm Digging Force
4,690 lbf
4,074 lbf
4,592 lbf
Bucket Digging Force
7,284 lbf
7,284 lbf
7,284 lbf
Rated Lift Capacity
2975 lb
2871 lb
2733 lb
Lift Radius
118 in
118 in
118 in
Boom Swing - Left
75°
75°
75°
Boom Swing - Right
55°
55°
55°
Maximum Dig Depth
121.2 in
133 in
153.2 in
Max Dump Height
137.2 in
144.3 in
154.5 in
Maximum Reach at Ground Level
194.5 in
205.9 in
225.3 in
Capacities
E32
E32 (Long-Arm)
E32 (Extendable Arm)
Fuel Tank
13.7 gal
13.7 gal
13.7 gal
Hydraulic System
E32
E32 (Long-Arm)
E32 (Extendable Arm)
Auxiliary Std Flow
16.9 gal/min
16.9 gal/min
16.9 gal/min
Auxiliary Pressure
2,987 psi
2,987 psi
2,987 psi
Dimension
E32
E32 (Long-Arm)
E32 (Extendable Arm)
Length
183.7 in
187.3 in
187.6 in
Overall Length in Travel Position
183.7 in
187.3 in
187.6 in
Width
61.8 in
61.8 in
61.8 in
Height
96.2 in
96.2 in
96.2 in
Height with Operator Cab
96.2 in
96.2 in
96.2 in
Features
E32
E32 (Long-Arm)
E32 (Extendable Arm)
Air Conditioning
Optional
Optional
Optional
Cab Enclosure
Optional
Optional
Optional
Cab Heater
Not Applicable
Not Applicable
Not Applicable
Heater Air Conditioning
Optional
Optional
Optional
Radio
Optional
Optional
Optional
Tail Swing Type
Conventional
Conventional
Conventional
Engine Shutdown
Standard
Standard
Standard
Auxiliary Hydraulics
Standard
Standard
Standard
Secondary Auxiliary Hydraulics
Optional
Optional
Optional
Quick Tach System
Standard
Standard
Standard
Rubber Track
Standard
Standard
Standard
Selectable Auxiliary Hydraulic Flow
Standard
Standard
Standard
Angle Blade
Not Applicable
Not Applicable
Not Applicable
