Specs
PG100 Key Specifications
PG100
Runtime Hours @ 75% Load
37
Power Output @ 1800RPM
129 hp
Engine
PG100
Engine Make
Cummins
Displacement
3.8 l
Emissions Tier Level
Tier 4 Final
Aftertreatment Technology
DOC / SCR / DPF
Capacities
PG100
Diesel Exhaust Fluid (DEF) Capacity
14.7 gal
Fuel Tank Capacity
172 gal
Dimensions
PG100
Length
166.1 in
Width
72.5 in
Height
94.7 in
Prime Power Rating
PG100
@ 480V-3-phase, 0.8PF, 60Hz
100 kVA (80 kW), 120 Amps
@ 240V-3-phase, 0.8PF, 60Hz
100 kVA (80 kW), 241 Amps
@ 208V-3-phase, 0.8PF, 60Hz
100 kVA (80 kW), 278 Amps
@ 240V-single-phase, 1.0PF, 60Hz
72 kVA (72 kW), 300 Amps
@ 120V-single-phase, 1.0PF, 60Hz
72 kVA (72 kW), 300 x 2 Amps
@ 400V-3-phase, 0.8PF, 50H
100 kVA (80 kW), 144 Amps
Voltage Configuration
3-Position Switch
Runtime Hours @ 75% Load
37
Sound Level
67 dB(A)
Frequency Capability
50Hz/60Hz Switchable
Power Output @ 1800RPM
129 hp
