Specs
S450 Key Specifications
S450 <!-->
Horsepower
49 hp
Rated Operating Capacity (ISO)
1,370 lb
Operating Weight
5370 lb
Auxiliary Std Flow
16.7 gal/min
Joystick Control
Optional -->
Engine
--> S450 <!-->
Emissions Tier (EPA)
Tier 4 -->
Engine Cooling
Liquid <!-->
Engine Fuel
Diesel -->
Horsepower
49 hp
Turbocharged Engine
yes <!-->
Performance
--> S450 <!-->
Rated Operating Capacity (ISO)
1,370 lb
Tipping Load
2740 lb
Operating Weight
5370 lb
Travel Speed
7.6 mph
Travel Speed (2-speed option)
9.2 mph
Capacities
--> S450 <!-->
Fuel Tank
14.2 gal
Hydraulic System
--> S450 <!-->
System Relief @ Quick Couplers
3,300 psi
Auxiliary Std Flow
16.7 gal/min
Dimension
--> S450 <!-->
Length
98.4 in
Length without Attachment
98.4 in
Length with Standard Bucket
124.9 in
Width
58.6 in
Width (with bucket)
62 in
Height
77.8 in
Height with Operator Cab
77.8 in
Height to Bucket Hinge Pin
109.5 in
Reach @ Maximum Height
20.8 in
Turning Radius
76.4 in
Wheelbase
35.4 in
Features
--> S450 <!-->
Joystick Control
Optional -->
Air Conditioning
Optional <!-->
Adjustable Seat
Standard -->
Backup Alarm
Standard <!-->
BICS System (Interlock)
Standard -->
Cab Enclosure
Optional <!-->
Sound Option
Optional -->
Cab Heater
Optional <!-->
Operating Lights
Standard -->
Parking Brake
Standard <!-->
Radio
Optional -->
Rear Window
Standard <!-->
Top Window
Standard -->
Lift-Arm Support
Standard <!-->
Seat Belt
Standard -->
Suspension Seat
Optional <!-->
Two Speed Travel
Optional -->
Deluxe Instrumentation
Optional <!-->
Engine Shutdown
Standard -->
Hydraulic Bucket Positioning
Optional <!-->
High Flow Option
Not Applicable -->
Auxiliary Hydraulics
Standard <!-->
Spark Arrestor Muffler
Standard -->
Bob-Tach Attachment System
Standard <!-->
Power Bob-Tach
Optional -->
ACS (Switchable Controls)
Not Applicable <!-->
Ride Control
Optional -->
Rear Hydraulics
Optional <!-->
Horn
Standard -->
Tires
<!--> S450 -->
