Specs
S510 Key Specifications
S510
Horsepower
55 hp
Rated Operating Capacity (ISO)
1876 lbs
Operating Weight
6208 lbs
Auxiliary Std Flow
17.1 gpm
Joystick Control
Optional
Engine
S510
Horsepower
55 hp
Performance
S510
Rated Operating Capacity (ISO)
1876 lbs
Tipping Load
3560 lbs
Operating Weight
6208 lbs
Travel Speed
7.6 mph
Capacities
S510
Fuel Tank
24.8 gal
Hydraulic System
S510
System Relief @ Quick Couplers
3550 psi
Auxiliary Std Flow
17.1 gpm
Dimensions
S510
Length without Attachment
104.6 in
Length with Standard Bucket
133 in
Width
64.7 in
Width (with bucket)
68 in
Height with Operator Cab
77.8 in
Height to Bucket Hinge Pin
114.5 in
Reach @ Maximum Height
17 in
Turning Radius
80 in
Wheelbase
42.6 in
Controls
S510
Instrumentation
S510
Price
S510
Additional Product Information
S510
Features
S510
Joystick Control
Optional
Air Conditioning
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
Sound Option
Optional
Cab Heater
Optional
Operating Lights
Standard
Parking Brake
Standard
Radio
Optional
Rear Window
Standard
Top Window
Standard
Lift-Arm Support
Standard
Seat Belt
Standard
Suspension Seat
Standard
Two Speed Travel
Standard
Deluxe Instrumentation
Optional
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Optional
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
ACS (Switchable Controls)
Not Applicable
Ride Control
Optional
Rear Hydraulics
Optional
Horn
Standard
BobQuote
S510
