Specs
UT6066 Key Specifications
UT6066
Horsepower
66.4 hp
Lift Capacity at 24" behind Lift Point
3898 lbs
PTO HP
57.4 hp
Width
77.2 in
Turning Radius
147 in
Wheelbase
82.7 in
Transmission Type
3 Range Powershuttle (w/electronic clutch)
Engine
UT6066
Engine Model
4HT-TP4A
Horsepower
66.4 hp
Displacement
149 cubic in
RPM
2600
Number of Cylinders
4
Performance
UT6066
Operating Weight
5440 lbs
Tractor Operating Weight
5440 lbs
Travel Speed
19.8 mph
Travel Speed - Reverse
19.5 mph
Lift Capacity at 24" behind Lift Point
3898 lbs
3-pt Lift Control Type
Position with Draft Control
Rear PTO - RPM
540
PTO HP
57.4 hp
Capacities
UT6066
Fuel Tank
22.4 gal
Hydraulic System
UT6066
Implement Hydraulic Flow
11 gpm
Steering Hydraulic Flow
6.9 gpm
Total Hydraulic Flow
17.9 gpm
Dimensions
UT6066
Length
148.8 in
Width
77.2 in
Height
102.1 in
Ground Clearance
12.3 in
Turning Radius
147 in
Wheelbase
82.7 in
Drive System
UT6066
Brake Type
Wet Multi Disc
Transmission Type
3 Range Powershuttle (w/electronic clutch)
