Contact us for price

Stock status: Call Store for Availability

The Bobcat® UT6566 helps you stay comfortable and confident while tackling projects. Its high performance and next-level implement versatility get the job done with efficiency and ease of use.

$54,354 USD*

Choose 0% financing for 48 months* or a $4,000 USD*/$5,200 CAD* rebate in lieu of financing on a UT6566 utility tractor.

Call Us Now

Specs

UT6566 Key Specifications

UT6566 <!-->
Horsepower
66.4 hp
Lift Capacity at 24" behind Lift Point
3,898 lb
PTO HP
51.1 hp
Transmission Type
3 Range Powershuttle (w/electronic clutch) -->
Width
77.2 in
Turning Radius
12' 3"
Wheelbase
6' 10"
<!-->


UT6566 <!-->
Emissions Tier (EPA)
Tier 4 -->
Horsepower
66.4 hp
Displacement
149 in³
Number of Cylinders
4 <!-->
Engine Model
4HT-TP4A -->
UT6566 -->
Operating Weight
5,830 lb
Travel Speed
19.8 mph
Travel Speed - Reverse
19.5 mph
3-Point Hitch
Category 2 <!-->
3-pt Lift Control Type
Position with Draft Control -->
Lift Capacity at 24" behind Lift Point
3,898 lb
Rear PTO System
Independent <!-->
Rear PTO - RPM
540 -->
PTO HP
51.1 hp
UT6566 -->
Fuel Tank
25.1 gal
UT6566 -->
Implement Hydraulic Flow
10.99 gal/min
Total Hydraulic Flow
19.23 gal/min
Steering Hydraulic Flow
8.24 gal/min
UT6566 -->
Brake Type
Wet Multi Disc <!-->
Transmission Type
3 Range Powershuttle (w/electronic clutch) -->
UT6566 -->
Length
148.8 in
Width
77.2 in
Height
99.3 in
Ground Clearance
12.3 in
Turning Radius
12' 3"
Wheelbase
6' 10"
Front Tire Size
Front Industrial (AG, multi-use) 12.5/80-18 (9.5-24, 340/80R18) <!-->
Rear Tire Size
Rear Industrial (AG, multi-use) 18.4-24 (16.9-30, 480/80R26) -->
UT6566 -->
Loader Lift Height
10' 9"
Lift Capacity at Bucket Pivot
3,017 lb
Bucket Width
6' 9"
<!-->


UT6566 Key Specifications

-->
UT6566 <!-->
Horsepower
66.4 hp
Lift Capacity at 24" behind Lift Point
3,898 lb
PTO HP
51.1 hp
Transmission Type
3 Range Powershuttle (w/electronic clutch) -->
Width
77.2 in
Turning Radius
12' 3"
Wheelbase
6' 10"
<!-->


Engine

-->
UT6566 <!-->
Emissions Tier (EPA)
Tier 4 -->
Horsepower
66.4 hp
Displacement
149 in³
Number of Cylinders
4 <!-->
Engine Model
4HT-TP4A -->

Performance

<!-->
UT6566 -->
Operating Weight
5,830 lb
Travel Speed
19.8 mph
Travel Speed - Reverse
19.5 mph
3-Point Hitch
Category 2 <!-->
3-pt Lift Control Type
Position with Draft Control -->
Lift Capacity at 24" behind Lift Point
3,898 lb
Rear PTO System
Independent <!-->
Rear PTO - RPM
540 -->
PTO HP
51.1 hp

Capacities

<!-->
UT6566 -->
Fuel Tank
25.1 gal

Hydraulic System

<!-->
UT6566 -->
Implement Hydraulic Flow
10.99 gal/min
Total Hydraulic Flow
19.23 gal/min
Steering Hydraulic Flow
8.24 gal/min

Drive System

<!-->
UT6566 -->
Brake Type
Wet Multi Disc <!-->
Transmission Type
3 Range Powershuttle (w/electronic clutch) -->

Dimension

<!-->
UT6566 -->
Length
148.8 in
Width
77.2 in
Height
99.3 in
Ground Clearance
12.3 in
Turning Radius
12' 3"
Wheelbase
6' 10"
Front Tire Size
Front Industrial (AG, multi-use) 12.5/80-18 (9.5-24, 340/80R18) <!-->
Rear Tire Size
Rear Industrial (AG, multi-use) 18.4-24 (16.9-30, 480/80R26) -->

Loader Attachment

<!-->
UT6566 -->
Loader Lift Height
10' 9"
Lift Capacity at Bucket Pivot
3,017 lb
Bucket Width
6' 9"
<!-->
-->
