Contact us for price

Stock status: Call Store for Availability

When you have more acres to maintain, you need more commercial-grade features to keep you on top. With the ZT3500, that comes standard.

Choose financing as low as 0% for 60 months* or a cash rebate of $800 USD*/ $1,000 CAD* on a ZT3500 zero-turn mower.

Call Us Now

Specs

ZT3500 Key Specifications

ZT3500 - 48” Deck <!-->
ZT3500 - 52” Deck -->
ZT3500 - 61” Deck <!-->
Mower Deck
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts -->
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts <!-->
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts -->
Width
48 in
52 in
61 in
Cutting Height
1.5-4.875 <!-->
1.5-4.875 -->
1.5-4.875 <!-->
Engine Model
Kaw FX651V -->
Kaw FX691V <!-->
Kaw FX730V -->
Displacement
726 cm³
726 cm³
726 cm³
Transmission type
HG ZT-3400 Hydrostatic Transaxles <!-->
HG ZT-3400 Hydrostatic Transaxles -->
HG ZT-3400 Hydrostatic Transaxles <!-->
Pump Displacement
12 cm³
12 cm³
12 cm³
-->


ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Mower Deck
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts <!-->
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts -->
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts <!-->
Width
48 in
52 in
61 in
Cutting Height
1.5-4.875 -->
1.5-4.875 <!-->
1.5-4.875 -->
Blade Tip Speed
17,365 ft/min
18,142 ft/min
18,809 ft/min
Discharge Chute
Flexible Molded Polymer <!-->
Flexible Molded Polymer -->
Flexible Molded Polymer <!-->
ZT3500 - 48” Deck <!-->
ZT3500 - 52” Deck -->
ZT3500 - 61” Deck <!-->
Engine Model
Kaw FX651V -->
Kaw FX691V <!-->
Kaw FX730V -->
Displacement
726 cm³
726 cm³
726 cm³
Fuel Capacity
7.8 gal
7.8 gal
7.8 gal
Horsepower
21.5 hp
22 hp
24 hp
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Weight
773 lb
789 lb
832 lb
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Transmission type
HG ZT-3400 Hydrostatic Transaxles <!-->
HG ZT-3400 Hydrostatic Transaxles -->
HG ZT-3400 Hydrostatic Transaxles <!-->
Pump Displacement
12 cm³
12 cm³
12 cm³
Oil Capacity
4 qt_liq_us -->
4 qt_liq_us <!-->
4 qt_liq_us -->
Forward Speed
10 mph
10 mph
10 mph
Reverse Speed
3.5 mph
3.5 mph
3.5 mph
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Charging System
15 A
15 A
15 A
Clutch
125 ft·lbf
125 ft·lbf
125 ft·lbf
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Front/Rear
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing <!-->
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing -->
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing <!-->
Length
76 in
76 in
79 in
ZT3500 - 48” Deck <!-->
ZT3500 - 52” Deck -->
ZT3500 - 61” Deck <!-->
Drive Wheel
23 x 10.5-12 -->
23 x 10.5-12 <!-->
23 x 10.5-12 -->
Front Caster Wheel Size
13 x 6.5-6 <!-->
13 x 6.5-6 -->
13 x 6.5-6 <!-->
Caster Arm Attachment
Welded to Frame -->
Welded to Frame <!-->
Welded to Frame -->
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Seat
High-Back, Spring Suspension Seat <!-->
High-Back, Spring Suspension Seat -->
High-Back, Spring Suspension Seat <!-->
Fore-Aft Adjust
Seat Slide Lever -->
Seat Slide Lever <!-->
Seat Slide Lever -->
<!-->


ZT3500 Key Specifications

-->
ZT3500 - 48” Deck <!-->
ZT3500 - 52” Deck -->
ZT3500 - 61” Deck <!-->
Mower Deck
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts -->
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts <!-->
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts -->
Width
48 in
52 in
61 in
Cutting Height
1.5-4.875 <!-->
1.5-4.875 -->
1.5-4.875 <!-->
Engine Model
Kaw FX651V -->
Kaw FX691V <!-->
Kaw FX730V -->
Displacement
726 cm³
726 cm³
726 cm³
Transmission type
HG ZT-3400 Hydrostatic Transaxles <!-->
HG ZT-3400 Hydrostatic Transaxles -->
HG ZT-3400 Hydrostatic Transaxles <!-->
Pump Displacement
12 cm³
12 cm³
12 cm³
-->


Deck

<!-->
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Mower Deck
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts <!-->
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts -->
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts <!-->
Width
48 in
52 in
61 in
Cutting Height
1.5-4.875 -->
1.5-4.875 <!-->
1.5-4.875 -->
Blade Tip Speed
17,365 ft/min
18,142 ft/min
18,809 ft/min
Discharge Chute
Flexible Molded Polymer <!-->
Flexible Molded Polymer -->
Flexible Molded Polymer <!-->

Engine

-->
ZT3500 - 48” Deck <!-->
ZT3500 - 52” Deck -->
ZT3500 - 61” Deck <!-->
Engine Model
Kaw FX651V -->
Kaw FX691V <!-->
Kaw FX730V -->
Displacement
726 cm³
726 cm³
726 cm³
Fuel Capacity
7.8 gal
7.8 gal
7.8 gal
Horsepower
21.5 hp
22 hp
24 hp

Performance

<!-->
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Weight
773 lb
789 lb
832 lb

Transmission

<!-->
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Transmission type
HG ZT-3400 Hydrostatic Transaxles <!-->
HG ZT-3400 Hydrostatic Transaxles -->
HG ZT-3400 Hydrostatic Transaxles <!-->
Pump Displacement
12 cm³
12 cm³
12 cm³
Oil Capacity
4 qt_liq_us -->
4 qt_liq_us <!-->
4 qt_liq_us -->
Forward Speed
10 mph
10 mph
10 mph
Reverse Speed
3.5 mph
3.5 mph
3.5 mph

Electrical

<!-->
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Charging System
15 A
15 A
15 A
Clutch
125 ft·lbf
125 ft·lbf
125 ft·lbf

Frame

<!-->
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Front/Rear
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing <!-->
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing -->
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing <!-->
Length
76 in
76 in
79 in

Wheels

-->
ZT3500 - 48” Deck <!-->
ZT3500 - 52” Deck -->
ZT3500 - 61” Deck <!-->
Drive Wheel
23 x 10.5-12 -->
23 x 10.5-12 <!-->
23 x 10.5-12 -->
Front Caster Wheel Size
13 x 6.5-6 <!-->
13 x 6.5-6 -->
13 x 6.5-6 <!-->
Caster Arm Attachment
Welded to Frame -->
Welded to Frame <!-->
Welded to Frame -->

Seat

<!-->
ZT3500 - 48” Deck -->
ZT3500 - 52” Deck <!-->
ZT3500 - 61” Deck -->
Seat
High-Back, Spring Suspension Seat <!-->
High-Back, Spring Suspension Seat -->
High-Back, Spring Suspension Seat <!-->
Fore-Aft Adjust
Seat Slide Lever -->
Seat Slide Lever <!-->
Seat Slide Lever -->
<!-->
-->
