Specs
ZT2000 Key Specifications
ZT2000 - 42" Deck <!-->
ZT2000 - 52" Deck -->
ZT2000 - 48" Deck <!-->
Mower Deck
TufDeck 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts -->
TufDeck 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts <!-->
TufDeck 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts -->
Width
42 in
52 in
48 in
Cutting Height
1.5-4.875 <!-->
1.5-4.875 -->
1.5-4.875 <!-->
Engine Model
Kaw FR651V -->
Kaw FR651V <!-->
Kaw FR651V -->
Displacement
726 cm³
726 cm³
726 cm³
Transmission type
HG ZT-2800 Hydrostatic Transaxles <!-->
HG ZT-2800 Hydrostatic Transaxles -->
HG ZT-2800 Hydrostatic Transaxles <!-->
Pump Displacement
10 cm³
10 cm³
10 cm³
Deck
<!--> ZT2000 - 42" Deck -->
ZT2000 - 52" Deck <!-->
ZT2000 - 48" Deck -->
Mower Deck
TufDeck 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts <!-->
TufDeck 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts -->
TufDeck 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts <!-->
Width
42 in
52 in
48 in
Cutting Height
1.5-4.875 -->
1.5-4.875 <!-->
1.5-4.875 -->
Blade Tip Speed
18,809 ft/min
18,142 ft/min
17,365 ft/min
Discharge Chute
Flexible Molded Polymer <!-->
Flexible Molded Polymer -->
Flexible Molded Polymer <!-->
Engine
--> ZT2000 - 42" Deck <!-->
ZT2000 - 52" Deck -->
ZT2000 - 48" Deck <!-->
Engine Model
Kaw FR651V -->
Kaw FR651V <!-->
Kaw FR651V -->
Displacement
726 cm³
726 cm³
726 cm³
Fuel Capacity
3.8 gal
3.8 gal
3.8 gal
Horsepower
21.5 hp
21.5 hp
21.5 hp
Performance
<!--> ZT2000 - 42" Deck -->
ZT2000 - 52" Deck <!-->
ZT2000 - 48" Deck -->
Weight
684 lb
752 lb
736 lb
Transmission
<!--> ZT2000 - 42" Deck -->
ZT2000 - 52" Deck <!-->
ZT2000 - 48" Deck -->
Transmission type
HG ZT-2800 Hydrostatic Transaxles <!-->
HG ZT-2800 Hydrostatic Transaxles -->
HG ZT-2800 Hydrostatic Transaxles <!-->
Pump Displacement
10 cm³
10 cm³
10 cm³
Oil Capacity
2.1 qt_liq_us
4 qt_liq_us -->
4 qt_liq_us <!-->
Forward Speed
7 mph -->
7 mph <!-->
7 mph -->
Reverse Speed
3 mph <!-->
3 mph -->
3 mph <!-->
Electrical
--> ZT2000 - 42" Deck <!-->
ZT2000 - 52" Deck -->
ZT2000 - 48" Deck <!-->
Charging System
15 A
15 A
15 A
Clutch
105 ft·lbf
105 ft·lbf
105 ft·lbf
Frame
--> ZT2000 - 42" Deck <!-->
ZT2000 - 52" Deck -->
ZT2000 - 48" Deck <!-->
Front/Rear
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing -->
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing <!-->
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing -->
Length
76 in
76 in
76 in
Wheels
<!--> ZT2000 - 42" Deck -->
ZT2000 - 52" Deck <!-->
ZT2000 - 48" Deck -->
Drive Wheel
20 x 8.0-10 <!-->
20 x 10.0-10 -->
20 x 10.0-10 <!-->
Front Caster Wheel Size
13 x 5.0-6 -->
13 x 5.0-6 <!-->
13 x 5.0-6 -->
Caster Arm Attachment
Welded to Frame <!-->
Welded to Frame -->
Welded to Frame <!-->
Seat
--> ZT2000 - 42" Deck <!-->
ZT2000 - 52" Deck -->
ZT2000 - 48" Deck <!-->
Seat
High-Back, Spring Suspension Seat -->
High-Back, Spring Suspension Seat <!-->
High-Back, Spring Suspension Seat -->
Fore-Aft Adjust
Seat Slide Lever <!-->
Seat Slide Lever -->
Seat Slide Lever <!-->
