Specs
ZT6100 Key Specifications
ZT6100 - 61” Deck <!-->
Mower Deck
AirFX™ Cutting System -->
Width
61 in
Cutting Height
1-5.5 in. <!-->
Engine Model
Kaw FX850V EFI -->
Displacement
852 cm³
Transmission type
HG ZT-4400 Hydrostatic Transaxles <!-->
Pump Displacement
12 cm³
Deck
<!--> ZT6100 - 61” Deck -->
Mower Deck
AirFX™ Cutting System <!-->
Width
61 in
Cutting Height
1-5.5 in. -->
Blade Tip Speed
18,500 ft/min
Discharge Chute
Flexible Molded Polymer <!-->
Engine
--> ZT6100 - 61” Deck <!-->
Engine Model
Kaw FX850V EFI -->
Displacement
852 cm³
Fuel Capacity
15 gal
Horsepower
29.5 hp
Performance
<!--> ZT6100 - 61” Deck -->
Weight
1464 lb
Transmission
<!--> ZT6100 - 61” Deck -->
Transmission type
HG ZT-4400 Hydrostatic Transaxles <!-->
Pump Displacement
12 cm³
Oil Capacity
2.5 qt_liq_us
Forward Speed
12 mph
Reverse Speed
4 mph -->
Electrical
<!--> ZT6100 - 61” Deck -->
Charging System
15 A
Clutch
225 ft·lbf
Frame
<!--> ZT6100 - 61” Deck -->
Front/Rear
Welded 0.25 in, 7-gauge Steel; 1.5 x 2.5 in Steel Tubing <!-->
Length
83 in
Wheels
--> ZT6100 - 61” Deck <!-->
Drive Wheel
24 x 12.0-12 -->
Front Caster Wheel Size
13 x 6.5-6 <!-->
Caster Arm Attachment
Bolt-On -->
Seat
<!--> ZT6100 - 61” Deck -->
Seat
Extra-High Back, Full-Mechanical Suspension Seat <!-->
Fore-Aft Adjust
Seat Slide Lever -->
