Specs
E26 Key Specifications
Operating Weight
6,489 lb
Bucket Digging Force
5,652 lbf
Maximum Reach at Ground Level
192 in
Width
61 in
Tail Swing Type
Minimal <!-->
<!-->
<!-->Engine
Emissions Tier (EPA)
Tier 4 -->
Engine Fuel
Diesel <!-->
Maximum Governed RPM
2,550 rpm
Turbocharged Engine
no -->
Optional Turbocharged Engine
N/A <!-->
Performance
Operating Weight
6,489 lb
Weight Class
2.9 t
Travel Speed - High
3.2 mph
Travel Speed - Low
1.8 mph
Arm Digging Force
3,547 lbf
Bucket Digging Force
5,652 lbf
Rated Lift Capacity
2359 lb
Lift Radius
118 in
Boom Swing - Left
70° -->
Boom Swing - Right
55° <!-->
Maximum Dig Depth
114.4 in
Max Dump Height
129.6 in
Maximum Reach at Ground Level
192 in
Capacities
Fuel Tank
9.1 gal
Hydraulic System
Auxiliary Std Flow
14.2 gal/min
Auxiliary Pressure
2,611 psi
Dimension
Length
170.4 in
Overall Length in Travel Position
170.4 in
Width
61 in
Height
96 in
Height with Operator Cab
96 in
Features
Air Conditioning
Optional -->
Cab Enclosure
Optional <!-->
Cab Heater
Optional -->
Heater Air Conditioning
Optional <!-->
Radio
Optional -->
Tail Swing Type
Minimal <!-->
Engine Shutdown
Standard -->
Auxiliary Hydraulics
Standard <!-->
Secondary Auxiliary Hydraulics
Not Applicable -->
Quick Tach System
Standard <!-->
Rubber Track
Standard -->
Selectable Auxiliary Hydraulic Flow
Standard <!-->
Angle Blade
Not Applicable -->
