Contact us for price

Stock status: Call Store for Availability

The time-tested E35 is our best-selling compact excavator, delivering proven performance on the most demanding jobsites. The zero-tail-swing E35 is designed with practical features that enhance durability, simplify routine maintenance and take operator productivity to a new level.

$55,083 USD**

Lease a E35 compact excavator for as low as $699 USD* per month. Offers end June 30, 2025.

Call Us Now

Specs

E35 Key Specifications

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)
Operating Weight
7659 lbs
7659 lbs
7659 lbs
7893 lbs
7893 lbs
7893 lbs
Bucket Digging Force
7284 lbf
7284 lbf
7284 lbf
7284 lbf
7284 lbf
7284 lbf
Maximum Reach at Ground Level
204.3 in
204.3 in
204.3 in
17 ft
17 ft
17 ft
Width
69.7 in
69.7 in
69.7 in
69.7 in
69.7 in
69.7 in

BobQuote

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)

Engine

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)
Maximum Governed RPM
2450 rpm
2450 rpm
2450 rpm
2400 rpm
2400 rpm
2400 rpm
Horsepower
24.8 hp
24.8 hp
24.8 hp
33 hp
33 hp
33 hp
Turbocharged Engine
no
no
no
yes
yes
yes

Performance

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)
Operating Weight
7659 lbs
7659 lbs
7659 lbs
7893 lbs
7893 lbs
7893 lbs
Weight Class
4 t
4 t
4 t
4 t
4 t
4 t
Travel Speed - High
2.9 mph
2.9 mph
2.9 mph
2.9 mph
2.9 mph
2.9 mph
Travel Speed - Low
1.6 mph
1.6 mph
1.6 mph
1.6 mph
1.6 mph
1.6 mph
Arm Digging Force
4690 lbf
4690 lbf
4690 lbf
4690 lbf
4690 lbf
4690 lbf
Bucket Digging Force
7284 lbf
7284 lbf
7284 lbf
7284 lbf
7284 lbf
7284 lbf
Rated Lift Capacity
3318 lbs
3318 lbs
3318 lbs
3318 lbs
3318 lbs
3318 lbs
Lift Radius
118 in
118 in
118 in
118 in
118 in
118 in
Boom Swing - Left
75 deg
75 deg
75 deg
75 deg
75 deg
75 deg
Boom Swing - Right
55 deg
55 deg
55 deg
55 deg
55 deg
55 deg
Maximum Dig Depth
121.2 in
121.2 in
121.2 in
11.1 ft
11.1 ft
11.1 ft
Max Dump Height
137.2 in
137.2 in
137.2 in
11.4 ft
11.4 ft
11.4 ft
Maximum Reach at Ground Level
204.3 in
204.3 in
204.3 in
17 ft
17 ft
17 ft
Ground Pressure (Steel)
4.7 psi
4.7 psi
4.7 psi
4.8 psi
4.8 psi
4.8 psi

Capacities

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)
Fuel Tank
13.7 gal
13.7 gal
13.7 gal
13.7 gal
13.7 gal
13.7 gal

Hydraulic System

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)
Auxiliary Std Flow
16.9 gpm
16.9 gpm
16.9 gpm
16.9 gpm
16.9 gpm
16.9 gpm
Auxiliary Pressure
2987 psi
2987 psi
2987 psi
2987 psi
2987 psi
2987 psi

Dimension

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)
Length
190 in
190 in
190 in
190 in
190 in
190 in
Overall Length in Travel Position
190 in
190 in
190 in
190 in
190 in
190 in
Width
69.7 in
69.7 in
69.7 in
69.7 in
69.7 in
69.7 in
Height
96.2 in
96.2 in
96.2 in
96.2 in
96.2 in
96.2 in
Height with Operator Cab
96.2 in
96.2 in
96.2 in
96.2 in
96.2 in
96.2 in
Minimum Turning Radius
N/A
N/A
N/A
N/A
N/A
N/A
Maximum Blade Drop (Below Grade)
17.9 in
17.9 in
17.9 in
17.9 in
17.9 in
17.9 in

Controls

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)

Features

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)
Air Conditioning
Optional
Optional
Optional
Optional
Optional
Optional
Swing Boom
Standard
Standard
Standard
Standard
Standard
Standard
Cab Enclosure
Optional
Optional
Optional
Optional
Optional
Optional
Cab Heater
Not Applicable
Not Applicable
Not Applicable
Not Applicable
Not Applicable
Not Applicable
Heater Air Conditioning
Optional
Optional
Optional
Optional
Optional
Optional
Radio
Optional
Optional
Optional
Optional
Optional
Optional
Engine Shutdown
Standard
Standard
Standard
Standard
Standard
Standard
Auxiliary Hydraulics
Standard
Standard
Standard
Standard
Standard
Standard
Secondary Auxiliary Hydraulics
Optional
Optional
Optional
Optional
Optional
Optional
Quick Tach System
Standard
Standard
Standard
Standard
Standard
Standard
Rubber Track
Standard
Standard
Standard
Standard
Standard
Standard
Selectable Auxiliary Hydraulic Flow
Standard
Standard
Standard
Standard
Standard
Standard
Angle Blade
Optional
Optional
Optional
Optional
Optional
Optional

Price

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)

Additional Product Information

E35
E35 (25 hp, Extendable Arm)
E35 (25 hp, Long-Arm)
E35 (33 hp)
E35 (33 hp, Extendable Arm)
E35 (33 hp, Long-Arm)
