Specs
PG190 Key Specifications
PG190
Runtime Hours @ 75% Load
46
Power Output @ 1800RPM
219 hp
Engine
PG190
Engine Make
Cummins
Displacement
6.7 l
Emissions Tier Level
Tier 4 Final
Aftertreatment Technology
DOC / SCR
Capacities
PG190
Diesel Exhaust Fluid (DEF) Capacity
24 gal
Fuel Tank Capacity
368 gal
Dimensions
PG190
Length
224 in
Width
83.2 in
Height
102.9 in
Prime Power Rating
PG190
@ 480V-3-phase, 0.8PF, 60Hz
181 kVA (145 kW), 218 Amps
@ 240V-3-phase, 0.8PF, 60Hz
181 kVA (145 kW), 436 Amps
@ 208V-3-phase, 0.8PF, 60Hz
181 kVA (145 kW), 503 Amps
@ 240V-single-phase, 1.0PF, 60Hz
110 kVA (110 kW), 458 Amps
@ 120V-single-phase, 1.0PF, 60Hz
110 kVA (110 kW), 458 x 2 Amps
@ 400V-3-phase, 0.8PF, 50H
165 kVA (132 kW), 238 Amps
Voltage Configuration
3-Position Switch
Runtime Hours @ 75% Load
46
Sound Level
69 dB(A)
Frequency Capability
50Hz/60Hz Switchable
Power Output @ 1800RPM
219 hp
