Specs
S70 Key Specifications
S70
Horsepower
23.5 hp
Rated Operating Capacity (ISO)
760 lbs
Operating Weight
2892 lbs
Auxiliary Std Flow
9.8 gpm
Joystick Control
Not Applicable
Engine
S70
Horsepower
23.5 hp
Performance
S70
Rated Operating Capacity (ISO)
760 lbs
Tipping Load
1520 lbs
Operating Weight
2892 lbs
Travel Speed
6.3 mph
Capacities
S70
Fuel Tank
6.5 gal
Hydraulic System
S70
Auxiliary Std Flow
9.8 gpm
Dimensions
S70
Length without Attachment
75.6 in
Length with Standard Bucket
97.3 in
Width
35.5 in
Width (with bucket)
36 in
Height with Operator Cab
71.4 in
Height to Bucket Hinge Pin
94.5 in
Reach @ Maximum Height
15.8 in
Standard Bucket
36 in
Standard Tires
23 x 5.7-12, 4PR
Controls
S70
Instrumentation
S70
Price
S70
Additional Product Information
S70
Features
S70
Joystick Control
Not Applicable
Air Conditioning
Not Applicable
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
Sound Option
Optional
Cab Heater
Optional
Operating Lights
Standard
Parking Brake
Standard
Radio
Not Applicable
Rear Window
Standard
Top Window
Optional
Lift-Arm Support
Standard
Seat Belt
Standard
Suspension Seat
Standard
Two Speed Travel
Not Applicable
Deluxe Instrumentation
Not Applicable
Engine Shutdown
Not Applicable
High Flow Option
Not Applicable
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Not Applicable
Ride Control
Not Applicable
Rear Hydraulics
Not Applicable
Horn
Standard
