Specs
E10e Key Specifications
E10e <!-->
Battery Type
Lithium Ion -->
System Voltage
51.8 V
Gross Battery Capacity
11.52 kW·h
Maximum Dig Depth
76.9 in
Maximum Reach at Ground Level
121.8 in
Operating Weight
2,648 lb
Width
27.9 in
Electrical System
--> E10e <!-->
Battery Type
Lithium Ion -->
System Voltage
51.8 V
Gross Battery Capacity
11.52 kW·h
Interior Sound Level According to ISO 6396
72 dB
External Sound Level According to ISO 6395
85 dB
Estimated Run Time
4 h <!-->
On-Board Charge Time - 120V
10-12 h -->
On-Board Charge Time - 240V
10-12 h <!-->
Off-Board Charge Time
2 h -->
Engine
<!--> E10e -->
Performance
<!--> E10e -->
Travel Speed - High
1.8 mph
Travel Speed - Low
1.1 mph
Arm Digging Force
1,248 lbf
Bucket Digging Force
1,865 lbf
Rated Lift Capacity
704 lb
Lift Radius
79 in
Boom Swing - Left
67° <!-->
Boom Swing - Right
64° -->
Maximum Dig Depth
76.9 in
Max Dump Height
71.6 in
Maximum Reach at Ground Level
121.8 in
Operating Weight
2,648 lb
Weight Class
1 t <!-->
Hydraulic System
--> E10e <!-->
Auxiliary Std Flow
5.3 gal/min
Auxiliary Pressure
2,756 psi
Dimension
--> E10e <!-->
Length
110 in
Overall Length in Travel Position
110 in
Width
27.9 in
Height
87 in
Height with Operator Cab
87 in
Features
--> E10e <!-->
Air Conditioning
Not Applicable -->
Cab Enclosure
Not Applicable <!-->
Cab Heater
Not Applicable -->
Heater Air Conditioning
Not Applicable <!-->
Radio
Not Applicable -->
Tail Swing Type
Zero <!-->
Auxiliary Hydraulics
Standard -->
Secondary Auxiliary Hydraulics
Standard <!-->
Quick Tach System
Not Applicable -->
Rubber Track
Standard <!-->
Selectable Auxiliary Hydraulic Flow
Not Applicable -->
Angle Blade
Not Applicable <!-->
On-Board Charger
Standard -->
Off-Board Charger
Optional <!-->
J1772 Charge Cable with NEMA 14-50 Plug
Not Applicable -->
NEMA 5-15 Charge Cable
Standard <!-->
NEMA 14-50 Charge Cable
Optional -->
