Specs
T550 Key Specifications
T550
Rated Operating Capacity (ISO)
1995 lbs
Operating Weight
7557 lbs
Ground Pressure (Rubber)
4.9 psi
Auxiliary Std Flow
17.1 gpm
Joystick Control
Optional
BobQuote
T550
SSL Specs
T550
Engine
T550
Horsepower
68 hp
Torque (SAE NET)
176.7 ft-lb
Turbocharged Engine
yes
Performance
T550
Rated Operating Capacity (ISO)
1995 lbs
Operating Capacity (50% of Tip)
2850 lbs
Tipping Load
5700 lbs
Operating Weight
7557 lbs
Travel Speed
7.1 mph
Ground Pressure (Rubber)
4.9 psi
Capacities
T550
Fuel Tank
36.5 gal
Hydraulic System
T550
System Relief @ Quick Couplers
3500 psi
Auxiliary Std Flow
17.1 gpm
Raise Lift Arm
3.3 sec
Lower Lift Arm
2.8 sec
Bucket Dump
2.3 sec
Bucket Rollback
1.7 sec
Dimension
T550
Length
133 in
Length without Attachment
104.5 in
Length with Standard Bucket
133 in
Width
67 in
Width (with bucket)
68 in
Height
77.8 in
Height with Operator Cab
77.8 in
Height to Bucket Hinge Pin
114.5 in
Reach @ Maximum Height
17 in
Rollback Angle
30 deg
Turning Radius
80 in
Length of track on ground
54.1 in
Track Width
12.6 in
Track Width - Optional
15.8
Controls
T550
Vehicle Steering
Dual Levers
Instrumentation
T550
Features
T550
Joystick Control
Optional
Air Conditioning
Optional
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
ROPS/FOPS Approved
Standard
ROPS-Step
N/A
Sound Option
Optional
Cab Heater
Optional
Heater Air Conditioning
Optional
Operating Lights
Standard
Work Lights
Standard
Rear Window
Standard
Top Window
Standard
Grab Handles
N/A
Seat Belt
Standard
Suspension Seat
Standard
Two Speed Travel
Optional
Deluxe Instrumentation
Optional
Lockable Ignition
N/A
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
3-Spool Valve
N/A
Grease Track Tension
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
Ride Control
Not Applicable
Horn
Standard
Operation Cost
T550
Serviceability
T550
Drive System
T550
Chain Master Link
N/A
Price
T550
Additional Product Information
T550
