Specs
T66 Key Specifications
T66
Rated Operating Capacity (ISO)
2,450 lb
Operating Weight
8840 lb
Ground Pressure (Rubber)
5.8 psi
Auxiliary Std Flow
17.6 gal/min
Auxiliary High Flow
26.9 gal/min
Joystick Control
Optional
Engine
T66
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Fuel
Diesel
Horsepower
74 hp
Turbocharged Engine
yes
Performance
T66
Rated Operating Capacity (ISO)
2,450 lb
Operating Capacity (50% of Tip)
3500 lb
Tipping Load
7000 lb
Operating Weight
8840 lb
Travel Speed
7.2 mph
Travel Speed (2-speed option)
10.2 mph
Ground Pressure (Rubber)
5.8 psi
Capacities
T66
Fuel Tank
28.3 gal
Hydraulic System
T66
System Relief @ Quick Couplers
3,500 psi
Auxiliary Std Flow
17.6 gal/min
Auxiliary High Flow
26.9 gal/min
Dimension
T66
Length
134.9 in
Length without Attachment
107 in
Length with Standard Bucket
134.9 in
Width
67 in
Width (with bucket)
68 in
Height
80.5 in
Height with Operator Cab
80.5 in
Height to Bucket Hinge Pin
120 in
Reach @ Maximum Height
36.7 in
Turning Radius
81.5 in
Length of track on ground
54.3 in
Track Width
12.6 in
Track Width - Optional
15.7 in
Features
T66
5-Link Torsion Suspension Undercarriage
Optional
Joystick Control
Optional
Air Conditioning
Optional
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Heater
Optional
Operating Lights
Standard
Suspension Seat
Standard
Two Speed Travel
Optional
Deluxe Instrumentation
Optional
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
ACS (Switchable Controls)
Not Applicable
Ride Control
Optional
Horn
Standard
Cab Enclosure
Optional
Adjustable Seat
Standard
Sound Option
Optional
Rear Window
Standard
Top Window
Standard
Seat Belt
Standard 2-Point Lap Belt and Optional 3-Point Shoulder Belt on Two-Speed Models
Spark Arrestor Muffler
DOC
Lift-Arm Support
Standard
