Specs
T595 Key Specifications
Rated Operating Capacity (ISO)
2,200 lb
Operating Weight
8022 lb
Ground Pressure (Rubber)
5.1 psi
Auxiliary Std Flow
17.1 gal/min
Joystick Control
Standard <!-->
<!-->
<!-->Engine
Emissions Tier (EPA)
Tier 4 -->
Engine Cooling
Liquid <!-->
Engine Fuel
Diesel -->
Horsepower
70 hp
Turbocharged Engine
yes <!-->
Performance
Rated Operating Capacity (ISO)
2,200 lb
Operating Capacity (50% of Tip)
3142 lb
Tipping Load
6517 lb
Operating Weight
8022 lb
Travel Speed
7.1 mph
Ground Pressure (Rubber)
5.1 psi
Capacities
Fuel Tank
36.5 gal
Hydraulic System
System Relief @ Quick Couplers
3,550 psi
Auxiliary Std Flow
17.1 gal/min
Dimension
Length
133 in
Length without Attachment
104.5 in
Length with Standard Bucket
133 in
Width
67 in
Width (with bucket)
68 in
Height
77.8 in
Height with Operator Cab
77.8 in
Height to Bucket Hinge Pin
119 in
Reach @ Maximum Height
34.9 in
Turning Radius
80 in
Length of track on ground
54.1 in
Track Width
12.6 in
Track Width - Optional
15.7 in
Features
Joystick Control
Standard -->
Air Conditioning
Optional <!-->
Backup Alarm
Standard -->
BICS System (Interlock)
Standard <!-->
Cab Heater
Optional -->
Operating Lights
Standard <!-->
Suspension Seat
Standard -->
Two Speed Travel
Not Applicable <!-->
Deluxe Instrumentation
Optional -->
Engine Shutdown
Standard <!-->
Hydraulic Bucket Positioning
Optional -->
High Flow Option
Not Applicable <!-->
Auxiliary Hydraulics
Standard -->
Bob-Tach Attachment System
Standard <!-->
Power Bob-Tach
Optional -->
ACS (Switchable Controls)
Not Applicable <!-->
Ride Control
Optional -->
Horn
Standard <!-->
Cab Enclosure
Optional -->
Adjustable Seat
Standard <!-->
Sound Option
Optional -->
Rear Window
Standard <!-->
Top Window
Standard -->
Seat Belt
Standard <!-->
Spark Arrestor Muffler
Standard -->
